| adjusting knob | plated steel | ||
| body | zinc | ||
| elastomers | synthetic rubber | ||
| gauge port | rc1/8 | ||
| maximum inlet pressure pressure bar | 17 bar | ||
| operating temperature f temperature fahrenheit min to max range | -4 ... 176 °f | ||
| outlet pressure adjustment imperial pressure psig min to max range | 15 ... 145 psi | ||
| port connections | g3/4 | ||
| product style | plug-in | ||
| relief port | rc1/8 |
| adjusting screw | steel | ||
| bonnet | zinc | ||
| gauge | no gauge | ||
| maximum inlet pressure imperial pressure psi | 247 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -20 ... 80 °c | ||
| outlet pressure adjustment pressure bar min to max range | 1 ... 10 bar | ||
| Anschlussgröße | g1/4 | ||
| range | v64h | ||
| Baureihe | olympian plus |
