| valve operation | 5/2 | ||
| body | diecast aluminium | ||
| flow flow dm3sec | 41.33 dm3/sec | ||
| Handhilfsbetätigung | push and turn | ||
| nuts and screws | nickel plated steel | ||
| operating pressure psi pressure psi min to max range | 29 ... 116 psi | ||
| operating temperature temperature celsius min to max range | -5 ... 50 °c | ||
| range | v50…53 | ||
| springs | stainless steel |
| actuation | solenoid pilot / spring return | ||
| Elektrischer Anschluss | 22mm industrial standard | ||
| flow flow litresperminute | 2480 l/m | ||
| Medium | compressed air | ||
| operating pressure pressure bar min to max range | 2 ... 8 bar | ||
| operating temperature f temperature fahrenheit min to max range | 23 ... 122 °f | ||
| Anschlussgröße | g1/2 | ||
| spool | aluminium alloy |
