| Total Length H | 113 | mm | |
| Housing Width A | 25,50 | mm | |
| Bolt Hole Size N | 12 | mm | |
| Center of Bearing from Housing End A2 | 15 | mm | |
| Center of Bearing from Bearing End S | 12,70 | mm | |
| Bolt Size | M10 |
| Total Height L | 60 | mm | |
| Bolt Hole Spacing J | 90 | mm | |
| Flange Thickness A1 | 11 | mm | |
| Inner Ring Width B | 31 | mm | |
| Dimension A0 | 33,30 | mm |
| Bearing Number | UC202 | ||
| UPC Code | 87.796.074.156 | ||
| Housing Construction | Two-Bolt Flange |
| Shaft Size d | 15 | mm | |
| Locking Style | Set Screw Locking | ||
| Gewicht | 0,50 | Kg |
