| body | aluminium | ||
| data performance shelf life | 3 years | ||
| flow flow dm3sec | 11 dm3/sec | ||
| flow kv flow kv | 0.44 kv | ||
| materials | nickel plated brass | ||
| mil spec | available on request | ||
| operating pressure pressure bar min to max range | -0.9 ... 16 bar | ||
| operating temperature f temperature fahrenheit min to max range | -4 ... 176 °f | ||
| oring | nbr (silicone free) | ||
| product style | accessories | ||
| seal material | silicon free nitrile | ||
| tube sizes length millimetre | 6 mm |
| cracking pressure pressure bar | 0.03 bar | ||
| eu country of origin | china | ||
| flow flow litresperminute | 660 l/m | ||
| grabring | nickel plated brass | ||
| Medium | compressed air | ||
| od tube length millimetre | 6 mm | ||
| operating pressure psi pressure psi min to max range | -13 ... 232 psi | ||
| operating temperature temperature celsius min to max range | -20 ... 80 °c | ||
| Anschlussgröße | 6mm | ||
| range | t50 | ||
| springs | stainless steel |
