| Bore diameter | d | 30 | mm |
| Outside diameter locking ring | d2 | 48 | mm |
| Top width | A1 | 25 | mm |
| Overall bearing width | B | 37,20 | mm |
| Foot height | H1 | 17 | mm |
| Distance between attachment bolts | J | min.108 | |
| Diameter of attachment bolt hole | N | 14 | mm |
| Distance from locking device side face to raceway centre | s1 | 23,20 | mm |
| Shoulder diameter inner ring | d1 | ≈39.7 | |
| Base width | b | 40 | mm |
| Width including end cover | A5 | 22,50 | mm |
| Height of spherical seat centre | H | 42,90 | mm |
| Overall height | H | 82 | mm |
| Overall length | L | 152 | mm |
| Length of attachment bolt hole | N1 | 23,50 | mm |
