| Kabellänge | 30 m | ||
| Electrical connection proportional valve | Plugs Round design M9 7-pin | ||
| Produktgewicht | 400 g | ||
| Vibration resistance to DIN/IEC 68 Part 2-6 | Tested according to severity level 1 | ||
| Relative Luftfeuchtigkeit | 0 - 95% Non-condensing | ||
| Continuous shock resistance to DIN/IEC 68 Part 2-82 | Tested to severity level 2 | ||
| CE-Zeichen (siehe Konformitätserklärung) | To EU EMC Directive In accordance with EU RoHS Directive | ||
| Zulässige Spannungsschwankungen | +/- 25% | ||
| Current consumption input | 4 mA | ||
| Max. current consumption without proportional valve | 70 mA | ||
| Debounce time for inputs | 20 ms | ||
| Type of outputs | To IEC 61131-2 Positive logic (PNP) No galvanic isolation | ||
| Number of digital outputs | 5 | ||
| Operator controls | 3 keys Touch sensitive keyboard | ||
| Control signals | Remote/teach input/left/right Input, position 1/2/3/4 Error-Ready output Output, position 1/2/3/4 |
| Electrical connection encoder | 5-pin Socket M9 Round design | ||
| Electrical connection operating voltage, inputs and outputs | 15-pin Sub-D Plug | ||
| Umgebungstemperatur | 0 °C ... 50 °C | ||
| Schutzart | IP65 To IEC 60529 | ||
| LABS-Konformität | VDMA24364-B2-L | ||
| CE marking (see declaration of conformity) | To UK instructions for EMC To UK RoHS instructions | ||
| Zulassung | RCM trademark | ||
| Current rating per output | 100 mA | ||
| Nennbetriebsspannung DC | 24 V | ||
| Max. current consumption with proportional valve | 1,1 A | ||
| Type of inputs | To IEC 61131-2 Positive logic (PNP) No galvanic isolation | ||
| Number of digital inputs | 8 | ||
| Fuse capacity of outputs | Electronic Max. tripping current 500 mA All outputs | ||
| Anzeige | 3-digit Red colour 7-segment display | ||
| Data backup | Flash memory |
