FESTO SDAT
10 Produkte
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO SDAT – Position transmitter, magnetic. Finden Sie das passende Produkt durch Filtern mit Measuring range und Switching input/output.
SDAT Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| SDAT | SDAT-M-HS- -1-L- -E-0.3-M8 | Position transmitter, magnetic |
Typcode zur Katalognummer SDAT,
SDAT-M-HS- -1-L- -E-0.3-M8
| 001 | Series |
|---|---|
| SDAT | Position transmitter, magnetic |
| 002 | Sensor version |
| M | Can be inserted in the slot |
| 003 | Sensor principle |
| HS | Hall sensor |
| 004 | Measuring range |
| M50 | 50 mm |
| M80 | 80 mm |
| M100 | 100 mm |
| M125 | 125 mm |
| M160 | 160 mm |
| 005 | Nominal operating voltage |
| 1 | 24 V DC |
| 006 | Display |
|---|---|
| L | LED |
| 007 | Switching input/output |
| SA | PNP, 1 analogue output 4 ... 20 mA, IO-Link |
| SV | PNP, 1 analogue output 0 ... 10 V, IO-Link |
| 008 | Cable characteristic |
| E | Suitable for energy chains/robot applications |
| 009 | Cable length [m] |
| 0.3 | 0.3 m |
| 010 | Electrical connection |
| M8 | Plug M8, A-coded |
