| Length total | L | 138 | mm |
| Höhe | T | 42 | mm |
| Basic static load capacity | C0 | 209,000 |
| Breite | B | 40 | mm |
| Basic dynamic load capacity | C | 122,000 |
| Mounting dimension | JB | 6 | mm |
| Hexagon socket adjusting screw | S1 | 6 | mm |
| Size thread k DIN | K | M6 | |
| Screw stroke A | Amax | 10 | mm |
| Adjustment screw revolution | 0,05 | mm |
| Lubrication connector DIN3405-A | K | M6 | |
| Hexagon socket counter forcing screw | S2 | 3 | mm |
| Tightening torque fixing screws | K3 MA max | 12,54 | Nm |
| Adjustment maximum | Delta hmax | 0,52 | mm |
