| ras max - Max shaft & housing fillet radius | 0,3 mm | ||
| Tmax - Max operating temperature | 120 °C | ||
| Nlim - Oil lubrication limit speed | 26000 tr/min | ||
| C0r - Static load rating | 4,9 kN | ||
| Radial clearance class | CN | ||
| k - Hole diameter | 2 mm | ||
| rs - Min fillet radius | 0,3 mm |
| Da max - Max shoulder diameter OR | 14 mm | ||
| Tmin - Min operating temperature | -20 °C | ||
| Nlim - Grease lubrication limit speed | 17000 tr/min | ||
| Cr - Dynamic load rating | 4,85 kN | ||
| Lubrication hole on inner ring | No | ||
| Lubrication hole on outer ring | Yes | ||
| Brand | NTN |
