| inner diameter (mm) | 100 | ||
| Width (mm) | 16 | ||
| preload | preloaded | ||
| outer diameterd - mm | 140 | ||
| widthb b1 - mm | 16 | ||
| greasing hole - b - mm | 1,60 | ||
| shoulder height - ds(max) - mm | 109 | ||
| basic load rating - radial - dynamicratingc - kn | 31,70 | ||
| mass - kg | 0,83 |
| outer diameter (mm) | 140 | ||
| dust protection seal | with seal | ||
| inner diameterd - mm | 100 | ||
| roller pitch circle diameterdp - mm | 119,30 | ||
| greasing hole - a - mm | 3,50 | ||
| rmin - mm | 1 | ||
| shoulder height - dh(min) - mm | 129 | ||
| basic load rating - radial - staticratingc0 - kn | 48,60 |
