| adjusting knob | acetal resin | ||
| body | zinc | ||
| data performance b10 value number of cycles | 5000000 | ||
| elastomers | nitrile rubber | ||
| flow flow dm3secbar | 33 dm3/(s.bar) dm3/sec | ||
| gauge | no gauge | ||
| maximum inlet pressure imperial pressure psi | 58 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -34 ... 65 °c | ||
| outlet pressure adjustment pressure bar min to max range | 0.3 ... 4 bar | ||
| Anschlussgröße | g1/4 | ||
| range | r72r | ||
| replaced flag | yes | ||
| Baureihe | excelon |
| adjusting screw | steel | ||
| bonnet | acetal | ||
| data performance shelf life | 3 years | ||
| flow flow dm3sec | 33 dm3/sec | ||
| flow type | reverse flow | ||
| gauge port | rc1/8 | ||
| maximum inlet pressure pressure bar | 4 bar | ||
| operating temperature f temperature fahrenheit min to max range | -30 ... 150 °f | ||
| outlet pressure adjustment imperial pressure psig min to max range | 4 ... 60 psi | ||
| partially replaced part | r82r-2gk-rfg|r82r-2gk-rfn | ||
| product style | modular | ||
| relievingnonrelieving | relieving | ||
| retrieve price | true |
