| activation | electrically | ||
| voltage tolerance dc | -15% / +10% | ||
| electrical connection number of poles | 3-pin | ||
| control pressure max. | 8 bar | ||
| max. ambient temperature | 50 °c | ||
| max. medium temperature | 50 °c | ||
| Einschaltdauer | 100 % | ||
| mounting screw tightening torque | 0.9 nm | ||
| delivery unit | 1 piece | ||
| seal material | acrylonitrile butadiene rubber |
| dc operating voltage | 24 v | ||
| electrical connection size | m8x1 | ||
| control pressure min. | 3 bar | ||
| min. ambient temperature | 5 °c | ||
| min. medium temperature | 5 °c | ||
| power consumption dc | 2 w | ||
| mounting screws | hexalobular socket (torx) iso 10664-10 | ||
| tightening torque tolerance | ±0,1 mt | ||
| Gehäusematerial | polyamide |
