| activation | electrically | ||
| switching principle | 5/2-directional valve with air spring return | ||
| working pressure min. | -0.9 bar | ||
| dc operating voltage | 24 v | ||
| Handhilfsbetätigung | with detent | ||
| electrical connection size | iso 15217, form c | ||
| Dichtprinzip | soft seal | ||
| pilot valve width | 15 mm | ||
| Anschlussart | pipe connection, plate connection | ||
| blocking principle | plate principle | ||
| control pressure min. | 3 bar | ||
| min. ambient temperature | -10 °c | ||
| min. medium temperature | -10 °c |
| nominal flow qn | 800 l/min | ||
| compressed air connection output | 1/8-27 nptf | ||
| working pressure max | 10 bar | ||
| voltage tolerance dc | -10% / +10% | ||
| electrical connection type | plug | ||
| actuating control | single solenoid | ||
| pilot | external | ||
| valve type | spool valve, positive overlapping | ||
| return | with air spring return | ||
| can be assembled into blocks | can be assembled into blocks | ||
| control pressure max. | 10 bar | ||
| max. ambient temperature | 50 °c |
