| regulation range min. | 0.5 bar | ||
| working pressure min. | 0 bar | ||
| Hysterese | < 0,05 bar | ||
| Medium | compressed air | ||
| min. ambient temperature | -10 °c | ||
| min. medium temperature | -10 °c | ||
| dc operating voltage | 24 v | ||
| Schutzklasse | ip65 | ||
| permissible ripple | 5% | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| Typ | poppet valve | ||
| compressed air connection output | g 1/4 | ||
| electrical connection size | m12 |
| regulation range max. | 6 bar | ||
| working pressure max | 11 bar | ||
| repetitive precision | < 0,04 bar | ||
| nominal flow qn | 550 l/min | ||
| max. ambient temperature | 60 °c | ||
| max. medium temperature | 60 °c | ||
| Max. Stromaufnahme | 120 ma | ||
| Anzeige | led | ||
| max. particle size | 40 µm | ||
| oil content of compressed air max. | 5 mg/m³ | ||
| compressed air connection input | g 1/4 | ||
| compressed air connection, exhaust | g 1/4 |
