| regulation range min. | 0 bar | ||
| actual output value | 0 ... 20 ma | ||
| Elektrischer Anschluss | via signal connection | ||
| max. power consumption | 300 ma | ||
| mounting orientation | ±α = 0 ... 90° ±β = 0 ... 90° | ||
| dc operating voltage | 24 v | ||
| nominal flow qn | 120 l/min | ||
| compressed air connection output | g 1/8, 1/8 npt | ||
| max. ambient temperature | 50 °c | ||
| working pressure max | 12 bar | ||
| certificates | ce declaration of conformity |
| nominal input value | 0 ... 20 ma | ||
| signal connection | 5-pin | ||
| Schutzklasse | ip65 | ||
| permissible ripple | 5% | ||
| Hysterese | < 0,05 bar | ||
| control | analog | ||
| Medium | compressed air | ||
| compressed air connection input | g 1/8, 1/8 npt | ||
| min. ambient temperature | 0 °c | ||
| working pressure min. | 0.5 bar | ||
| Typ | poppet valve |
