| Hysterese | adjustable | ||
| switching point | adjustable 0 ... 100% | ||
| repeatability (% of full scale value) | ± 0,2 % | ||
| Schwingfestigkeit | 5 g (10 - 150 hz) | ||
| protection against overpressure | 16 bar | ||
| units displayed | inhg, mpa, bar, kpa, psi | ||
| measurement | relative pressure | ||
| Medium | compressed air (max. 40 μm) | ||
| min. medium temperature | 0 °c | ||
| min. ambient temperature | 0 °c | ||
| compressed air connection type | push-in fitting | ||
| operating pressure max | 12 bar | ||
| operating voltage dc, max. | 30 v dc |
| resetting point | adjustable 0 ... 100% | ||
| switching time | < 5 ms | ||
| precision (% of full scale value) | ±1.5% in temperature range of 10 - 30°c, ± 2 % including temperature drift | ||
| shock resistance max. | 30 g | ||
| switching logic | no/nc (adjustable) | ||
| Anzeige | lcd display, 4 digits, color setting: green or red | ||
| oil content of compressed air max. | 40 mg/m³ | ||
| max. medium temperature | 60 °c | ||
| max. ambient temperature | 60 °c | ||
| compressed air connection | Ø 4 | ||
| certificates | free of substances that impair surface wetting in the coating process, conforms with reach, ce declaration of conformity, culus, rohs | ||
| operating pressure min | 0 bar |
