| activation | electrically | ||
| nozzle Ø | 1.5 mm | ||
| accessories | with non-return valve | ||
| working pressure max | 6 bar | ||
| min. ambient temperature | 0 °c | ||
| min. medium temperature | 0 °c | ||
| Medium | compressed air | ||
| oil content of compressed air max. | 1 mg/m³ | ||
| max. suction capacity | 64.3 l/min | ||
| max. vacuum level at p.opt | 81.5 % | ||
| protection against overpressure (max.) | 5 bar | ||
| protection class according to en 60529:2000, without electrical connector | ip65 |
| with silencer | with silencer | ||
| vacuum switch | electronic | ||
| working pressure min. | 2 bar | ||
| working pressure p.opt. | 4 bar | ||
| max. ambient temperature | 50 °c | ||
| max. medium temperature | 50 °c | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| max. particle size | 5 µm | ||
| air consumption at p.opt. | 98.9 l/min | ||
| sound pressure level intake effect | 79 db | ||
| release valve | release valve | ||
| duty cycle according to din vde 0580 standard | 100 % |
