| Funktion | 2 x pnp | ||
| mounting orientation | s (vertical) | ||
| precision (% of full scale value) | ± 3 % | ||
| operating pressure max | 10 bar | ||
| compressed air connection | Ø 1,2x1 | ||
| working pressure max | 10 bar | ||
| max. ambient temperature | 60 °c | ||
| max. medium temperature | 50 °c | ||
| oil content of compressed air max. | 1 mg/m³ | ||
| Anzeige | led | ||
| operating pressure display | 2 led | ||
| shock resistance max. | 10 g | ||
| repeatability (% of full scale value) | ± 1 % |
| Typ | with sensor element based on piezo resistance | ||
| output signal digital | 2 x pnp | ||
| operating pressure min | 0 bar | ||
| compressed air connection type | flange with o-ring | ||
| working pressure min. | 0 bar | ||
| min. ambient temperature | 0 °c | ||
| min. medium temperature | 0 °c | ||
| Medium | compressed air | ||
| measurement | relative pressure | ||
| switching logic | no (make contact) | ||
| protection against overpressure | 15 bar | ||
| Schwingfestigkeit | 10 - 55 hz, 0,1 mm |
