| material, front cover | steel | ||
| Dämpfung | elastic | ||
| weight 10 mm stroke | 0.26 kg | ||
| max. retracted stroke setting | -5 mm | ||
| extracting piston force | 253 n | ||
| working pressure max | 7 bar | ||
| oil content of compressed air max. | 1 mg/m³ | ||
| max. ambient temperature | 60 °c | ||
| pressure for determining piston forces | 6,3 bar | ||
| Medium | compressed air | ||
| Funktionsprinzip | double-acting | ||
| Hub | 20 mm |
| max. play (radial) | 0.6 ° | ||
| weight +10 mm stroke | 0.027 kg | ||
| cushioning energy max. | 0.11 j | ||
| speed max. | 0.5 m/s | ||
| retracting piston force | 189 n | ||
| working pressure min. | 1.5 bar | ||
| oil content of compressed air min. | 0 mg/m³ | ||
| min. ambient temperature | 0 °c | ||
| max. particle size | 5 µm | ||
| magnetic piston | with magnetic piston | ||
| port | m5 | ||
| piston Ø | 16 mm |
