| B3 | 4,30 | mm | |
| CF | 20 | F7 | |
| Cp | 75 | d12 | |
| D3 | 11 | mm | |
| e | 117 | ||
| Toleranz für FM | ± 0.2 | ||
| L1 | 4,50 | mm | |
| l4 | 10 | ||
| L11 | 27 | ||
| R4 | 32 | ||
| Drehmoment | 4 | mm | |
| Tg | 89 |
| Toleranz für B3 | ± 0.2 | ||
| CG | 25 | D10 | |
| D | 55 | mm | |
| D4 | 18 | ||
| FM | 41 | ||
| DIN 912 | M10x20 | ||
| Toleranz für L1 | ± 0.5 | ||
| Toleranz für L4 | ± 0.5 | ||
| Toleranz für L11 | - 0.5 | ||
| SR | 20 | ||
| Toleranz fürT | ± 0.2 | ||
| Toleranz für TG | ± 0.2 |
| Fmax | 22.900 | N |
| Maschinenschutz | 2,04 | kg |
