| KK | M10x1,25 | ||
| A2 | 37 | mm | |
| D6 | 6,60 | mm | |
| E1 | 36 | mm | |
| E2 | 23 | mm | |
| H | 24 | mm | |
| Schalter | 17 | ||
| Spiel (min ... max) | 0.4 mm ... 0.8 mm |
| A1 | 60 | mm | |
| D1 | 20 | mm | |
| D7 | 11 | mm | |
| Toleranz für E1 | ± 0.15 | ||
| Toleranz für E2 | ± 0.15 | ||
| H1 | 15 | mm | |
| T2 | 7 | mm | |
| Spiel (min ... max) | 1.9 mm ... 2.3 mm |
| Fmax | Fmax EMC |
| Maschinenschutz | 0,30 | kg |
