1)
Axial angle equalization
2)
Radial centerline movement
| B1 | 8 | mm | |
| D2 | 45 | mm | |
| Kraft | 30 | mm | |
| Linie | 103 | mm | |
| L2 | 30 | mm | |
| Toleranz für L3 | ± 1 | ||
| SW1 | 30 | mm | |
| SW3 | 24 | mm | |
| Spiel (min ... max) | 0.05 mm ... 0.5 mm |
| D1 | 32 | mm | |
| D3 | 22 | mm | |
| KK | M16x1,5 | ||
| Toleranz für L | ± 2 | ||
| l3 | 9 | ||
| RV | 1 | ||
| SW2 | 20 | mm | |
| SW4 | 41 | mm |
| Fmax (Value applies to size 63; Fmax. EMC for size 50. ) | 10.300 | N |
| Maschinenschutz | 0,65 | kg |
