REXROTH R169429360 ball runner block resist cr

Name: R169429360 REXROTH
Brand: REXROTH
SKU: 113512-de-eur
Price: 420.4 EUR
Availability: InStock

KWC-025-SNN-C0-H-2

420,40 €

1 Stk. mit 1 bis 3 Tagen Lieferzeit nach United States

Finden Sie Ihre passende Kombination! Klicken Sie hier, um passende Führungsleisten für diesen Laufwagen zu entdecken

Technische Daten

Area of application: For restricted upward and longitudinal space
Maximum precision
Significantly reduced frictional oscillations and low friction level, particularly under external load
Ball Runner Block body or ball Guide Rail made of steel with corrosion-resistant coating, matt silver finish, hard chrome plated
Patented entry zone increases the travel accuracy up to a factor of six

Ball runner block Resist CR with corrosion-resistant coating, matt silver finish, hard chrome plated

Baureihe (R1694)	Slimline, normal, low R1694
Baugröße (2)	25 size
Vorspannungsklasse (9)	C0 Without preload (clearance)

Genauigkeitsklasse (3)	H Hight Accuracy Level
Dichtungen (60)	SS Standard seal without ball chain

Dimensions
Technical data

^a) For O-ring
Size 20 - 25: Ø 5 · 1.0 (mm)
Open lube port if necessary (see general technical notes and information in the "Maintenance" section).
^b) Lube nipple, size 20 - 25:
Funnel-type lube nipple DIN 3405-B M3x5, B₂ = 8 mm
Lube port with additional anti-twist feature.
When using different lube nipples, pay attention to the screw-in depth of 5 mm!
The lube nipple is included in the scope of delivery (not installed).
Size 20: Connection is possible on end-face.
Size 25: Connection is possible on all sides.

S₂	M6
A₁	24	mm
A₃	12,50	mm
B₁	57,80	mm
E₂	35	mm
E₉	8,50	mm
H₁	26,50	mm
Dimension H₂ ohne Abdeckstreifen	24,25	mm
K₂	17	mm
K₄	4,10	mm
N₆	15.2 mm ±0.5
Drehmoment	60	mm
ØS₅	7	mm

Industriekomponente	48	mm
A₂	23	mm
B	81 mm +0.5
E₁	35	mm
E₈	38,30	mm
H	33	mm
Dimension H₂ mit Abdeckstreifen	24,45	mm
K₁	16,60	mm
K₃	4,10	mm
N₃	7	mm
S₉	M3x5
V₁	7,50	mm

a_max (If F_comb > 2.8 • F_pr : a_max = 50 m/s²)	250	m/s²
Maschinenschutz	0,45	kg
Betriebsbedingungen	Operating conditions
Zulässige Umgebungstemperatur (min ... max) (Up to 100 °C permissible for short periods. For operation at negative temperatures, please consult us. )	-10 °C ... +80 °C
