R16518142Y Bosch Rexroth

REXROTH R16518142Y KUGELWAGEN KOHLENSTOFFSTAHL

Name: R16518142Y REXROTH
Brand: REXROTH
SKU: 110643-de-eur
Price: 249.46 EUR
Availability: SoldOut

KWD-020-FNS-C1-N-1

249,46 €

Begrenzter Lagerbestand nur auf Anfrage erhältlich

Finden Sie Ihre passende Kombination! Klicken Sie hier, um passende Führungsleisten für diesen Laufwagen zu entdecken

Technische Daten

Area of application: For high rigidity requirements
Attachments on the Ball Runner Block can be mounted from above and below
Significantly reduced frictional oscillations and low friction level, particularly under external load
Maximum precision
Patented entry zone increases the travel accuracy up to a factor of six

Ball runner block CS, made of Carbon steel

Baureihe (R1651)	Flange, normal, standard height R1651...2
Baugröße (8)	20 size
Vorspannungsklasse (1)	C1 Moderate preload

Genauigkeitsklasse (4)	N Normal Accuracy Level
Dichtungen (2Y)	DS Double-lip seal with ball chain

Dimensions
Technical data

^a) For O-ring
Size 15: Ø 4 · 1.0 (mm)
Size 20 - 45: Ø 5 · 1.0 (mm)
Open lube port if necessary (see general technical notes and information in the "Maintenance" section).
^b) Recommended position for pin holes (dimension E₄ see general technical notes and information in the "Installation" section)
Rough-drilled holes may be present here from manufacturing. These may be bored open.
^c) Lube nipple, size 15 - 20:
Funnel-type lube nipple DIN 3405-A M3x5, B₂ = 1.6 mm
When using different lube nipples, pay attention to the screw-in depth of 5 mm!
Lube nipple, size 25 - 45:
Hydraulic-type lube nipple DIN 71412-A M6x8, B₂ = 9.5 mm
When using different lube nipples, pay attention to the screw-in depth of 8 mm!
The lube nipple is included in the scope of delivery (not installed).
Connection possible on all sides.
^d) Sealing plugs may be present here from manufacturing. Remove before mounting.

Industriekomponente	63	mm
A₂	20	mm
B	75 mm +0.5
E₁	53	mm
E₃	35	mm
E₉	7,30	mm
H₁	25,35	mm
Dimension H₂ ohne Abdeckstreifen	20,55	mm
K₂	11,80	mm
K₄	3,35	mm
N₂	5,20	mm
S₁	5,30	mm
ØS₅	6	mm
Drehmoment	60	mm

A₁	31,50	mm
A₃	21,50	mm
B₁	49,60	mm
E₂	40	mm
E₈	32,50	mm
H	30	mm
Dimension H₂ mit Abdeckstreifen	20,75	mm
K₁	11,80	mm
K₃	3,35	mm
N₁	7,70	mm
N₆	13.2 mm ±0.5
S₂	M6
S₉	M3x5
V₁	6	mm

a_max (If F_comb > 2.8 • F_pr : a_max = 50 m/s²)	500	m/s²
Maschinenschutz	0,45	kg
Betriebsbedingungen	Operating conditions
Zulässige Umgebungstemperatur (min ... max) (Up to 100 °C permissible for short periods. For operation at negative temperatures, please consult us. )	0 °C ... +80 °C

v_max	5	m/s
Maschinenschutz (Without friction of seal)	0,002 ... 0,003
Baugröße	20
