1)
for size 16x5/16x10
| T1 | 15 | mm | |
| H1 | 55 | mm | |
| Baugröße | 16x5R/L x 3 16x10R x 3 |
||
| Lochmuster | BB3 | ||
| Zylinderschraube mit Innensechskant | M8 | ||
| B | 35 mm ±0.01 | ||
| D6 | 40 | mm | |
| E2 | 20 mm ±0.1 | ||
| N | 10 | mm | |
| S1 | M10 | ||
| Spannlänge | 44 | L |
| S2 | M6 | ||
| H2 | 10 | mm | |
| Masse | 0,85 | g | |
| Lochmuster | BB7 | ||
| Industriekomponente | 40 | mm | |
| D1 | 28 | mm | |
| E1 | 52 mm ±0.1 | ||
| H | 28 mm ±0.01 | ||
| S | 8,40 | ||
| T2 | 10 | mm |
