REXROTH R072620600 DREHMOMENT-KUGELBUECHSE
KBDR4-FM-6DD
222,60 €
1 Stk.
mit 1 bis 3 Tagen Lieferzeit nach United States
Technische Daten
- For self-supporting, torsionally stiff guides with only one shaft
- With four ball guide grooves for transferring torque
- Matching shaft profiles with machined ball guide grooves
- Shafts machined to customer specification
- Integrated cross-roller bearing with initial lubrication
| Typ (KB) | Torque-resistant linear bushing, Miniature flanged, with four ball guide grooves, R0726 |
|---|---|
| Baureihe (DR) | Torque |
| Gleis (4) | Four ball guide grooves |
| Konstruktiver Aufbau (FM) | Miniature Flanged version |
|---|---|
| Wellendurchmesser (6) | 6 Shaft diameter |
| Dichtungen (DD) | With two seals |
