| adjusting knob | acetal resin | ||
| body | zinc | ||
| data performance shelf life | 3 years | ||
| flow flow dm3sec | 6.5 dm3/sec | ||
| flow imperial flow scfm | 14 scfm | ||
| gauge port | 1/8" npt | ||
| maximum inlet pressure imperial pressure psi | 125 psig | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -20 ... 65 °c | ||
| outlet pressure adjustment pressure bar min to max range | 0.3 ... 8.5 bar | ||
| product style | ported | ||
| relievingnonrelieving | relieving |
| Einstellung | knob | ||
| bonnet | acetal | ||
| elastomers | nitrile rubber | ||
| flow flow dm3secbar | 6.5 dm3/(s.bar) dm3/sec | ||
| gauge | no gauge | ||
| inner parts | brass | ||
| maximum inlet pressure pressure bar | 8.6 bar | ||
| operating temperature f temperature fahrenheit min to max range | -4 ... 149 °f | ||
| outlet pressure adjustment imperial pressure psig min to max range | 4 ... 125 psi | ||
| Anschlussgröße | 1/8" ptf | ||
| range | r07 | ||
| Baureihe | 07 series |
