REXROTH R069632089 DREHMOMENT-KUGELBUECHSE
KBDR2-20-WV-K
20,32 €
33,87 €
-40%
2 Stk.
mit 1 bis 3 Tagen Lieferzeit nach United States
Technische Daten
- For self-supporting, torsionally stiff guides with only one shaft
- With four ball guide grooves for transferring torque
- Matching shaft profiles with machined ball guide grooves
- Shafts machined to customer specification
- Integrated cross-roller bearing with initial lubrication
| Typ (KB) | Torque-resistant linear bushings, R0696 |
|---|---|
| Baureihe (DR) | Torque |
| Gleis (2) | Two ball guide grooves |
| Wellendurchmesser (20) | 20 Shaft diameter |
|---|---|
| Shaft (WV) | Shaft included |
| Wellenlänge (K) | Shaft length cut to size |
