a)
Recommended installation
b)
Retaining ring
| D | 42 | mm | |
| B | 20 | ||
| C3 | 31,20 | H12 | |
| D1 | 32 | mm | |
| D3 | 40 | mm | |
| Sicherungsring (Seeger-Orbis GmbH) | SB42 |
| Industriekomponente | 28 | mm | |
| B | 45 | ||
| C4 | 1,60 | H13 | |
| D2 | 35,10 | mm | |
| D4 | 43,20 |
| Maschinenschutz | 0,20 | kg | |
| Zulässige Umgebungstemperatur (min ... max) | -10 °C ... +80 °C |
| Betriebsbedingungen | Operating conditions |
