REXROTH R061104010 STANDARDKUGELBUECHSE

Name: R061104010 REXROTH
Brand: REXROTH
SKU: 29534-de-eur
Price: 94.99 EUR
Availability: InStock

KBM-E-40-D

94,99 €

50+ Stk. mit 1 bis 3 Tagen Lieferzeit nach United States

Technische Daten

Rugged all-metal design with steel ball retainer for harsh environments and heavy contamination
Many pockets acting as lubricant reservoirs for extended lubrication intervals or lubrication for life
For use in woodworking, foundries, cement plants
Stainless steel for the medical, chemistry and food industries
Integrated wiper seals

Typ (KB)	Standard linear bushings adjustable, with one wiper seal, R0611
Baureihe (M)	Standard (metal)
Form (E)	Adjustable

Wellendurchmesser (40)	40 Shaft diameter
Dichtungen (D)	One seal

a_max	100	m/s²
Maschinenschutz	0,62	kg
Losbrechkraft (One wiper seal: Multiply by a factor of 0.5.)	24	N
Kugelreihen	6
Radialspiel der Welle h6/Bohrung K7	+ 39 - 1
Zulässige Umgebungstemperatur (min ... max) (Only unsealed Linear Bushings with steel ball retainers may be used at higher temperatures. Make allowance for reductions in load capacity. )	-10 °C ... +80 °C

v_max	2,50	m/s
F_R (One wiper seal: Multiply by a factor of 0.5.,Frictional drags generated by Linear Bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication. )	8	N
Maschinenschutz (Friction coefficients of unsealed Linear Bushings when lubricated with oil. The friction coefficient is lowest under heavy load, but can still be above the specified value even under a low load. )	0,001 ... 0,004
Radialspiel der Welle h6/Bohrung H7	+ 60 + 20
Betriebsbedingungen	Operating conditions
