1)
Countersink for thread M ISO 4762, number N
2)
Type 1
3)
Type 2
4)
Type 3
5)
Type 4
| Baugröße | CKK-/CKR-110/145; VKK-070; FMS/FMB | ||
| B | 8,50 | ||
| D | 11,50 | mm | |
| Kraft | 19,30 | mm | |
| G | 14 | mm | |
| Anzahl der Löcher | 4 | N |
| Industriekomponente | 107 | mm | |
| C | 30 | mm | |
| e | 4,80 | ||
| Gewinde (Countersink ISO 4762) | M5 | ||
| H | 7 | mm |
