| length per package | 3 m | ||
| hose outside diameter | 0.375 inch | ||
| connection 1 thread size | 1/4 inch | ||
| maximum operating pressure | 15 bar, 1.5 mpa, 217,56 psi | ||
| Minimale Betriebstemperatur | -40 °f, -40 °c | ||
| division | low pressure connectors europe division | ||
| Anwendung | pneumatic, in-plant automotive, industrial assembly, machine tools, workshops | ||
| Produktfamilie | hose assemblies, pneumatic hose | ||
| Betriebsdruck | 15 bar, 217.56 psi, 1.5 mpa | ||
| design factor | 3 | ||
| compatible fitting | adaptors, plugs and manifolds, brass barbed fittings | ||
| specifications met | rohs, 2011/65/ec, ped, reach | ||
| hose inner tube material | polyurethane | ||
| weight (per unit of measure) | 0.21 kg/package | ||
| region of origin | germany | ||
| number of tubes | 1 |
| materials of construction | polyurethane with textile braid | ||
| cover color | blue | ||
| hose inside diameter | 0.248 inch | ||
| connection 1 type | bspp thread | ||
| Brand | legris | ||
| industry | industrial manufacturing equipement | ||
| technology | fluid & gas handling, pneumatics | ||
| product style | hose assemblies, pneumatic hose | ||
| vacuum pressure rating | 755 mm-hg, 29.72 inch-hg, 1 bar | ||
| media | water, pneumatic media | ||
| Maximale Betriebstemperatur | 75 °c | ||
| cover material | polyurethane | ||
| hose reinforcement material | textile braid | ||
| package type | reel | ||
| Gewicht | 0.047 lb/ft, 0.07 kg/m | ||
| for fluid type | pneumatic media, water |
