| Nut diameter lower tolerance | -0,50 | mm | |
| Nut width upper tolerance | 0,30 | mm | |
| Upper distance ring groove tolerance | 0,20 | mm | |
| Width, outer ring | C | 17 | mm |
| Diameter of groove | D1 | 59,60 | mm |
| Width retaining slot | b | 1,90 | mm |
| Distance ring grooves | C1 | 11,20 | mm |
| Fatigue load limit, radial | Cur | 410 | N |
| Basic dynamic load rating, radial | Cr | 14,000 | |
| Außen-Ø | D | 62 | mm |
| Basic static load rating, radial | C0r | 7,800 | |
| Breite | B | 32 | mm |
| Bore diameter | d | 25 | mm |
