| r1a - Max fillet radius | 1 mm | ||
| Da max - Max shoulder diameter OR | 65,5 mm | ||
| da max - Small face shoulder max diameter | 40 mm | ||
| BSF - Characteristic rolling element frequency | 4,468 Hz | ||
| BPFI - Characteristic inner ring frequency | 7,282 Hz | ||
| Tmax - Max operating temperature | 120 °C | ||
| Nlim - Grease lubrication limit speed | 9300 tr/min | ||
| Cu - Fatigue limit load | 6,15 kN | ||
| C - Dynamic load | 63 kN | ||
| r1s - Min fillet radius | 1,1 mm | ||
| F - Under roller diameter | 40,5 mm | ||
| Brand | NTN |
| ra max - Max fillet radius | 1 mm | ||
| db min - Min inner ring GO diameter | 44 mm | ||
| da min - Min shoulder diameter IR | 36,5 mm | ||
| FTF - Characteristic cage frequency | 0,393 Hz | ||
| BPFO - Characteristic outer ring frequency | 4,718 Hz | ||
| Tmin - Min operating temperature | -20 °C | ||
| Nlim - Oil lubrication limit speed | 13200 tr/min | ||
| C0 - Static load | 50 kN | ||
| Radial clearance class | CN | ||
| rs - Min fillet radius | 1,1 mm | ||
| E - Upper roller diameter | 62,5 mm |
