| Bore diameter | d | 40 | mm |
| Width of the bearing | B | 32 | mm |
| Basic static load rating, radial | C0r | 89,000 | |
| Speed on permanent grease lubrication | nD G | 650 | 1/min |
| Permissible dynamic load outer ring, radial | Fr per | 76,000 |
| Außen-Ø | D | 80 | mm |
| Basic dynamic load rating, radial | Cr | 39,500 | |
| Fatigue load limit, radial | Cur | 13,200 | |
| Permissible static load, radial | F0r per | 89,000 |
| Width, outer ring | C | 30 | mm |
| Minimum chamfer dimension | rmin | 1,10 | mm |
| Outside diameter of thrust washer | d2 | 66 | mm |
