| rotational speed limit1 - min-1 | 20.000 | ||
| outer diameter (mm) | 19 | ||
| dust protection seal | no seal | ||
| inner diameterdi - mm | 6 | ||
| b - mm | 12 | ||
| a - mm | 14 | ||
| oil holed1 - mm | 1,50 | ||
| basic load rating - static c0 - kn | 3,35 | ||
| mass - g | 20,50 |
| inner diameter (mm) | 6 | ||
| outer ring shape | spherical | ||
| Width (mm) | 12 | ||
| outer diameterd - mm | 19 | ||
| c - mm | 11 | ||
| rsmin - mm | 0,30 | ||
| basic load rating - dynamic c - kn | 3,33 | ||
| track load capacity - spherical outer ring - kn | 1,37 |
