| inner diameter (mm) | 45 | ||
| outer ring shape | spherical | ||
| Width (mm) | 32 | ||
| outer diameterd - mm | 85 | ||
| c - mm | 30 | ||
| rsmin - mm | 1 | ||
| basic load rating - dynamic c - kn | 80,50 | ||
| track load capacity - spherical outer ring - kn | 16,10 | ||
| mass - g | 935 |
| outer diameter (mm) | 85 | ||
| dust protection seal | no seal | ||
| inner diameterdi - mm | 45 | ||
| b - mm | 32 | ||
| a - mm | 66,50 | ||
| oil holed1 - mm | 3 | ||
| basic load rating - static c0 - kn | 183 | ||
| rotational speed limit1 - min-1 | 1.700 |
