| data performance shelf life | 10 years | ||
| flow flow dm3sec | 1 dm3/sec | ||
| induced air vacuum nlmin | 55 nl/min | ||
| Medium | compressed air | ||
| operating temperature f temperature fahrenheit min to max range | -4 ... 302 °f | ||
| height length millimetre | 30 mm | ||
| weight weight kilogram | 0.133 kg | ||
| Anschlussgröße | g1/4 | ||
| range | m/58112 | ||
| Thread Type | bspp |
| eu country of origin | germany | ||
| flow imperial flow scfm | 2 scfm | ||
| materials | brass | ||
| mil spec | available on request | ||
| operating temperature temperature celsius min to max range | -20 ... 150 °c | ||
| length length millimetre | 62 mm | ||
| width length millimetre | 30 mm | ||
| product style | pump | ||
| Baureihe | norgren vacuum | ||
| vacuum | -0.9 bar |
