| Gewicht | .33069 lb | ||
| ambient temperature (c) | 0 to 60 | ||
| pilot port size | m5 | ||
| maximum suck back volume (cm3) | 0,10 | ||
| withstand pressure (mpa) | 1 | ||
| flow characteristics - av x 10-6m2 | ? | ||
| note 1)tubing o.d. - inch sizes | (1/8), (3/16), 1/4 | ||
| Baureihe | lvc23 |
| mass (kg) | 0,08 | ||
| fluid temperature (c) | 0 to 100 | ||
| pilot air pressure (mpa) | 0.3 to 0.5 | ||
| operating pressure (mpa) | 0 to 0.2 | ||
| flow characteristics - cv | ? | ||
| orifice diameter | ? | ||
| note 1)tubing o.d. - metric sizes | (3), (4), 6 |
