| Material thread seal | PTFE | ||
| Material screw-in stud | Nickel-plated brass | ||
| LABS-Konformität | VDMA24364-B1/B2-L | ||
| Nominal flow rate closed | 340 l/min | ||
| Konstruktiver Aufbau | Directly actuated piston regulator With through compressed air supply | ||
| Actuator lock | Counter-locking | ||
| Werkstoff Gehäuse | PBT-reinforced | ||
| Eingangsdruck 1 | 0 psi ... 130,5 psi | ||
| Nominal flow rate open | 474 l/min | ||
| Pneumatischer Anschluss 2 | QS-8 | ||
| Controller function | Differential pressure constant With return flow function |
| Werkstoff-Hinweis | RoHS-compliant | ||
| Produktgewicht | 67 g | ||
| Hinweis zum Betriebs-/Steuermedium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Symbol | 00991535 | ||
| Einbaulage | optional | ||
| Betriebsmedium | Compressed air to ISO 8573-1:2010 [7:-:-] | ||
| Umgebungstemperatur | 0 °C ... 60 °C | ||
| Druckregelbereich | 2 bar ... 6 bar | ||
| Befestigungsart | Screw-in | ||
| Pneumatischer Anschluss 1 | G3/8 |
