FESTO LR
80 Produkte
Technische Daten
Entdecken Sie alle verfügbaren Konfigurationen für die Produktserie FESTO LR – Pressure regulator. Finden Sie das passende Produkt durch Filtern mit Pneumatischer Anschluss, Ausführung, Pressure gauge, Additional function, Baugröße und Display unit.
LR Typcodes
| Serie | Katalognummernformat | Beschreibung |
|---|---|---|
| LR | LR- -7- | Pressure regulator |
Typcode zur Katalognummer LR,
LR- -7-
| 001 | Series |
|---|---|
| LR | Pressure regulator |
| 002 | Pneumatic connection |
| None | |
| 1/8 | Female thread G1/8 |
| 1/4 | Female thread G1/4 |
| 3/8 | Female thread G3/8 |
| 1/2 | Female thread G1/2 |
| 3/4 | Female thread G3/4 |
| 1 | Female thread G1 |
| 003 | Version |
| D | D series, metal |
| DB | D series, polymer |
| 004 | Pressure regulation range |
| 7 | 0.5 ... 7 bar (0.05 ... 0.7 MPa) 0.5 ... 12 bar (0.05 ... 1.2 MPa) |
| 005 | Pressure gauge |
|---|---|
| With pressure gauge | |
| O | Without pressure gauge |
| 006 | Additional function |
| None | |
| I | With integrated non-return function |
| DI | Directly actuated pressure regulator with integrated return fl ow function |
| 007 | Size |
| MINI | Grid dimension 40 mm (without connecting plates) |
| MIDI | Grid dimension 55 mm (without connecting plates) |
| MAXI | Grid dimension 66 mm (without connecting plates) |
| 008 | Display unit |
| Bar/psi/without | |
| MPA | MPa |
