| body | aluminium | ||
| bowl capacity volume litre | 0.2 l/s | ||
| Ablauftyp | closed bowl | ||
| flow flow dm3sec | 73 dm3/sec | ||
| fog type | micro fog | ||
| maximum inlet pressure pressure bar | 17 bar | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -34 ... 80 °c | ||
| product style | modular | ||
| range | l74m | ||
| Baureihe | excelon |
| bowl | diecast aluminium | ||
| bowl type | metal with liquid level indicator | ||
| elastomers | neoprene | ||
| flow flow dm3secbar | 73 dm3/(s.bar) dm3/sec | ||
| maximum inlet pressure imperial pressure psi | 246 psig | ||
| maximum operating pressure imperial pressure psig | 250 psig psig | ||
| operating temperature f temperature fahrenheit min to max range | -30 ... 176 °f | ||
| Anschlussgröße | g1/2 | ||
| quick fill nipple | without | ||
| retrieve price | true | ||
| start point flow dm3sec | 0.94 dm3/sec |
