| body | aluminium | ||
| bowl capacity volume litre | 0.1 l/s | ||
| Ablauftyp | manual | ||
| flow flow dm3sec | 28 dm3/sec | ||
| flow imperial flow scfm | 60 scfm | ||
| maximum inlet pressure imperial pressure psi | 246 psig | ||
| maximum operating pressure imperial pressure psig | 250 psig psig | ||
| operating temperature f temperature fahrenheit min to max range | -30 ... 176 °f | ||
| partially replaced part | l84c-3ap-edn | ||
| product style | modular | ||
| range | l73c | ||
| retrieve price | true | ||
| start point flow dm3sec | 0.71 dm3/sec |
| bowl | diecast aluminium | ||
| bowl type | metal with liquid level indicator | ||
| elastomers | neoprene | ||
| flow flow dm3secbar | 28 dm3/(s.bar) dm3/sec | ||
| fog type | oil fog | ||
| maximum inlet pressure pressure bar | 17 bar | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -34 ... 80 °c | ||
| Anschlussgröße | 3/8" ptf | ||
| quick fill nipple | without | ||
| replaced flag | yes | ||
| Baureihe | excelon |
