| Anschlussgröße | g1/4 | ||
| bowl | polycarbonate | ||
| bowl type | polymer | ||
| Ablauftyp | manual | ||
| flow flow dm3sec | 24 dm3/sec | ||
| flow imperial flow scfm | 51 scfm | ||
| maximum inlet pressure imperial pressure psi | 145 psig | ||
| maximum operating pressure imperial pressure psig | 145 psig psig | ||
| operating temperature f temperature fahrenheit min to max range | -30 ... 122 °f | ||
| partially replaced part | l82m-2gp-epn | ||
| range | l72m | ||
| retrieve price | true | ||
| start point flow dm3sec | 0.94 dm3/sec |
| body | zinc | ||
| bowl capacity volume litre | 0.05 l/s | ||
| cadfilestep | norgren-l72m-2xp-qln.step | ||
| elastomers | geolast® | ||
| flow flow dm3secbar | 24 dm3/(s.bar) dm3/sec | ||
| fog type | micro fog | ||
| maximum inlet pressure pressure bar | 10 bar | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -34 ... 50 °c | ||
| product style | modular | ||
| replaced flag | yes | ||
| Baureihe | excelon |
