| body | zinc | ||
| bowl capacity volume litre | 0.05 l/s | ||
| cadfilestep | norgren-l72c-2xp-qdn.step | ||
| elastomers | geolast® | ||
| flow flow dm3secbar | 24 dm3/(s.bar) dm3/sec | ||
| fog type | oil fog | ||
| maximum inlet pressure pressure bar | 17 bar | ||
| Medium | compressed air | ||
| operating temperature temperature celsius min to max range | -34 ... 65 °c | ||
| Anschlussgröße | 1/4" ptf | ||
| range | l72c | ||
| retrieve price | true | ||
| start point flow dm3sec | 0.47 dm3/sec |
| bowl | diecast zinc | ||
| bowl type | metal with liquid level indicator | ||
| Ablauftyp | manual | ||
| flow flow dm3sec | 24 dm3/sec | ||
| flow imperial flow scfm | 51 scfm | ||
| maximum inlet pressure imperial pressure psi | 246 psig | ||
| maximum operating pressure imperial pressure psig | 250 psig psig | ||
| operating temperature f temperature fahrenheit min to max range | -30 ... 149 °f | ||
| partially replaced part | l82c-2ap-edn | ||
| product style | modular | ||
| replaced flag | yes | ||
| Baureihe | excelon |
