| BSF - Characteristic rolling element frequency | 12,872 Hz | ||
| BPFI - Characteristic inner ring frequency | 14,542 Hz | ||
| Tmax - Max operating temperature | 100 °C | ||
| Nlim - Grease lubrication limit speed | 4000 tr/min | ||
| C0r - Static load rating | 88,5 kN | ||
| Radial clearance class | CN | ||
| Maximum tightening torque | 360 N-m | ||
| e - Inlet diameter of roller or washer | 43 mm | ||
| C1 - Distance between roller face and washer face | 1 mm | ||
| G - Stud thread designation | M30X1.5 | ||
| B1 - Total stud length | 100 mm | ||
| F - Under roller diameter | 38 mm | ||
| Brand | NTN |
| FTF - Characteristic cage frequency | 0,461 Hz | ||
| BPFO - Characteristic outer ring frequency | 12,458 Hz | ||
| Tmin - Min operating temperature | -20 °C | ||
| Track load capacity spherical outer ring | 9,8 kN | ||
| Cr - Dynamic load rating | 45 kN | ||
| Bearing with/without cage | With | ||
| R - Track roller radius | 500 mm | ||
| m - Designation of the threaded lubrication hole | PT 1/8 | ||
| G1 - Thread length of the stud | 32 mm | ||
| B2 - Stud rod length | 63 mm | ||
| B - Bearing/Inner ring width | 37 mm | ||
| d1 - Stud diameter | 30 mm |
