| Werkstoff Gehäuse | Aluminium | ||
| Werkstoff-Hinweis | RoHS-compliant | ||
| Pneumatischer Anschluss 4 | Sub-base size 4 to ISO 5599-1 | ||
| Pneumatischer Anschluss 2 | Sub-base size 4 to ISO 5599-1 | ||
| Pilot air port 14 | Sub-base size 4 to ISO 5599-1 | ||
| Befestigungsart | On sub-base Via through-hole and screw | ||
| Umgebungstemperatur | -10 °C ... 60 °C | ||
| Schalldruckpegel | 85 dB(A) | ||
| LABS-Konformität | VDMA24364-B1/B2-L | ||
| Betriebsmedium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| Steuerdruck | 2 bar ... 16 bar | ||
| Symbol | 00991037 | ||
| Steuerart | Direct | ||
| Handhilfsbetätigung | None | ||
| Einbaulage | optional | ||
| Abluftfunktion | With flow control option | ||
| Nennweite | 18 mm | ||
| Betriebsdruck | -0,9 bar ... 16 bar | ||
| Standard nominal flow rate | 6.000 l/min | ||
| Betätigungsart | Pneumatic |
| Werkstoff Dichtungen | NBR | ||
| Pneumatischer Anschluss 5 | Sub-base size 4 to ISO 5599-1 | ||
| Pneumatischer Anschluss 3 | Sub-base size 4 to ISO 5599-1 | ||
| Pneumatischer Anschluss 1 | Sub-base size 4 to ISO 5599-1 | ||
| Anschluss Steuerluft 12 | Sub-base size 4 to ISO 5599-1 | ||
| Produktgewicht | 1.800 g | ||
| Steuermedium | Compressed air to ISO 8573-1:2010 [7:4:4] | ||
| Mediumstemperatur | -10 °C ... 60 °C | ||
| Hinweis zum Betriebs-/Steuermedium | Lubricated operation possible (in which case lubricated operation will always be required) | ||
| Schaltzeit um | 20 ms | ||
| Überdeckung | Positive overlap | ||
| Strömungsrichtung | Reversible | ||
| ISO-Code | 401 | ||
| Entspricht Norm | ISO 5599-1 | ||
| Dichtprinzip | Soft | ||
| Rastermaß | 82 mm | ||
| Konstruktiver Aufbau | Piston gate valve | ||
| Pneumatischer Arbeitsanschluss | Sub-base size 4 to ISO 5599-1 G3/4 | ||
| Baubreite | 76 mm | ||
| Ventilfunktion | 5/2 double solenoid |
