| Gewicht | .41918 lb | ||
| weight (without accessories) - standard connections | 135 g (irv10-c08) | ||
| vac side tubing o.d. | ?6, ?8 ?1/4andquot;, ?5/16andquot; | ||
| knob resolution | 0.13 kpa or less | ||
| withstand pressure note 2) | 100 kpa (except with pressure gauge) | ||
| fluid | air |
| weight (without accessories) - single sided connections | 125 g (irv10a-c08) | ||
| set side tubing o.d. | ?6, ?8 ?1/4andquot;, ?5/16andquot; | ||
| ambient and fluid temperature | 5 to 60c | ||
| atmospheric intake consumption note 3) | 0.6 l/min (anr) or less | ||
| set pressure range note 1) | ?100 to ?1.3 kpa | ||
| Baureihe | irv10 |
