| Length | 40 m | ||
| Maximale Betriebstemperatur | 100 °c, 212 °f | ||
| maximum operating pressure | 580 psi, 40 bar | ||
| Minimale Betriebstemperatur | -40 °f, -40 °c | ||
| specifications met | bs 5118/34310 | ||
| minimum bend radius | 11.811 inch, 300 mm | ||
| Gewicht | 0.71 lb/ft, 1.06 kg/m | ||
| hose reinforcement material | 1 steel wire braid | ||
| hose i.d. (inch) | 0,98 |
| cover color | black | ||
| cover material | sbr/cr rubber compound | ||
| Anwendung | air | ||
| media | compressed air, industrial air i.e. compressed air with traces of oil | ||
| hose inside diameter | 0.984 inch, 25 mm | ||
| hose outside diameter | 1.496 inch, 38 mm | ||
| hose inner tube material | nbr rubber compound | ||
| hose i.d. (mm) | 25 |
