| hose i.d. (mm) | 25 | ||
| media | cold water, light-chemical media, mild chemicals (check your fluid compatibility with our catalogue chart)., coolants, water, hot water, air | ||
| Brand | parker | ||
| industry | general industrial | ||
| technology | fluid & gas handling | ||
| product style | delivery | ||
| hose inside diameter | 25 mm, 0.984 inch | ||
| minimum bend radius | 150 mm, 5.906 inch | ||
| cover color | green | ||
| Maximale Betriebstemperatur | 120 °c with peaks to 140, 248 °f with peaks to 284 | ||
| materials of construction | rubber | ||
| hose inner tube material | epdm rubber compound |
| Minimale Betriebstemperatur | -40 °c, -40 °f | ||
| Gewicht | 0.40 lb/ft, 0.60 kg/m | ||
| division | polymer hose division europe | ||
| Anwendung | multipurpose | ||
| Produktfamilie | air hose, transfer hose, water hose | ||
| maximum operating pressure | 300 psi, 2 mpa, 20 bar | ||
| hose outside diameter | 34 mm, 1.338 inch | ||
| design factor | 3:1 | ||
| compatible fitting | 64 series, 47 series | ||
| specifications met | parker specifications | ||
| cover material | epdm rubber compound | ||
| hose reinforcement material | synthetic textile yarns |
